WH (SPEEDLine) Linear Units
The WH (SPEEDLine) series provides high-performance linear motion solutions for single-axis applications, with the flexibility to combine into two- and three-dimensional (X-Y-Z) systems. Featuring a lightweight, compact design with high load ratings, these units are especially effective for Z-axis applications requiring speed, precision, and durability.

Features:

• Maximum speed up to 10 m/s (33 ft/s)

• Acceleration up to 40 m/s² (131 ft/s²)

• Repeatability of ±0.05 mm (0.002 in.) under high feed forces

• Maximum feed force of 5,000 N (1,124 lbf)

• Payload capacity up to 9,300 N (2,090 lbf)

• Moment load capacity up to 930 Nm (209 lbf) on carriage

• Steel-reinforced belt drive for strength and reliability

• Rubber wipers protect the linear guide from debris

• Centralised lubrication system for reduced maintenance

• Lightweight, space-saving construction

• Manufactured in the U.S.

Recommended Uses:

• High-speed automation systems

• Multi-axis (X-Y-Z) motion applications

• Pick-and-place and handling systems

• Precision Z-axis operations

• Industrial assembly and packaging equipment
